1.8'' SPI LCD Module (128x160)

Overview

This 1.8" SPI LCD Module uses 4-pin SPI communication and has 128 x 160 pixel resolution and has its own buffer for pixel addresses. Its screen can display 18-bit of colors. Easy to use with any microprocessor, even small ones with less memory but with few pins available.

Specifications

• Size 1.8 "TFT LCD
• Resolution of 128 x 160, 18-bit color (262,144)
•  Driver Controller: ST7735R
• 4-wire SPI interface
• Compatible with 3.3 V or 5 V systems
• 3.3 V @ 150 mA regulator
• Drillings: 4 x 2 mm
• Dimensions: 34 x 56 x 6.5 mm
• Current: 50 mA

IO for the most streamlined wiring: (At least 3 IOs are required)

1. RST-directly connected to the single chip reset signal terminal, this IO can be saved

2. CS--connect to low level, the chip select is valid for a long time, this IO can be saved

3. AO--Connect IO control register selection

4. SDA--Connect IO to control data transmission

5. CLK--Connect IO to control SPI bus

6. LED--connect the high-level chip with 3.3V backlight and the IO can be saved

IO used for standard wiring: (6 IO)

1. RST--Connect IO to control LCD reset

2. CS--Connect IO control chip selection

3. AO--Connect IO control register selection

4. SDA--Connect IO to control data transmission

5. CLK--Connect IO to control SPI bus

6. LED--connect IO to control backlight on and off or PWM to control brightness
